ID5000 Series Industrial Barcode Reader

Product Introduction

Functional Features

1. Utilizes a 3.1MP high-performance global shutter sensor for superior image quality.

2. Built-in deep learning decoding algorithm adapts to diverse complex conditions with strong robustness.

3. Multiple lens interfaces available; optional mechanical focus lens enables automatic focusing for simplified setup.

4. Supports print quality grading to evaluate QR code printing quality.

5. Integrated controllable lighting module with diverse options.

6. IP67 protection withstands harsh industrial environments.

Ordering Model

MV-ID5030M-00C-NNN

*Product specifications may vary due to environmental factors. The company assumes no liability for any resulting consequences.

Product detailed parameters



Dimensions & Model Parameters


Model	Model	MV-ID5030M-00C-NNN
Model	Name	3.1MP Resolution, C - Mount, No Lens, No Light Source
Performance	Barcode Types	One - dimensional codes: Code 39,Code 93,Code 128(including GS1-128),CodaBar,EAN8,EAN13,UPCA,UPCE,ITF14,ITF25,Matrix 25,MSI,ChinaPost,Code 11,Industrial 25,Pharmacode etc. Two - dimensional codes: QR Code(含GS1-QR),Data Matrix(含GS1-DM),MicroQR,AZTEC etc. Stacked codes: PDF417 etc.
	Maximum Processing Frame Rate	60 fps
	Maximum Reading Speed	90 codes per second
	Sensor Type	CMOS, global shutter
	Pixel Size	2.5 μm × 2.5 μm
	Sensor Size	1/2”
	Resolution	2048 × 1536
	Exposure Time	16 μs ~ 1 sec
	Gain	1 dB ~ 4 dB
	Black/Color	Black and white
	Communication Protocol	SmartSDK,TCP Client,Serial,FTP,TCP Server,Profinet,Ethernet/IP,Melsec,Fins,ModBus,SLMP,UDP
Electrical Characteristics	Data Interface	Gigabit Ethernet(1000 Mbit/s)
	Digital I/O	12 - pin M12 connector provides power and I/O, including 3 optocoupler isolated inputs (Inline 0/1/2), 3 optocoupler isolated outputs (LineOut 3/4/5), 1 RS - 232 input, 1 RS - 232 output
	Power Supply	24 VDC
	Maximum Power Consumption	20W@24 VDC
Structure	Focal Length	/
	Lens Interface	C-Mount
	Lens Hood	Transparent lens hood
	Light Source	No built - in light source
	Indicators	Power indicator PWR, network indicators LNK/ACT, user indicators U1/U2
	Dimensions	109.5 mm × 64.4 mm × 109 mm
	Weight	Approximately 400 g
	IP Protection Rating	IP67 (when properly installed with the appropriate lens waterproof cover)
	Temperature	Operating temperature 0 - 50°C; Storage temperature - 30 - 70°C
	Humidity	20% ~ 95%RH, no condensation
General Specifications	Software	IDMVS
General Specifications	Certification	CE,RoHS,KC
